HDF Series - Single Tower Desiccant Air Dryers

Pressure dew points as low as -40°F (-40°C)

Features

A Spray Painter's Assurance For A Flawless Finish

State-of-the-art refinish materials and moisture-sensitive pneumatic tools require compressed air treatment. Modern spray guns, particularly HVLP, require greater volumes of air to atomize today's high-solids coatings. Greater volumes of air carry greater volumes of water, oil, and dirt which must be removed. A HDF Series compressed air dryer can eliminate that damaging water, dirt, and oil which can ruin your refinish work.

HDF Series Single Tower Desiccant Dryer Features:

  • Produce pressure dew points as low as -40°F (-40°C)
  • Rugged powder-painted, corrosion-resistant aluminum housing which can be installed in-line
  • Charge of silica gel desiccant adsorbs moisture from the compressed air
  • Desiccant change-out indicator offers convenient monitoring of desiccant condition
  • Desiccant change-out indicator turns color from blue to white
  • Integrated 15 micron cleanable dust filter

The benefits for your shop are:

  • Increased shop capacity to process more cars
  • Helps get on the "preferred" lists for referrals from insurance companies
  • Fewer labor hours and materials per paint job
  • Better bottom-line for the company

MODEL

FLOW CAPACITY
SCFM (NM3/H)

INLET/OUTLET
CONNECTIONS

OPTIONAL OIL
PREFILTRATION
PACKAGE

80 PSIG

5.5 BARG

100 PSIG

6.7 BARG

150 PSIG

10.3 BARG

IN

HDF1

4

7

5

9

7

12

1/4

HDF1-F

HDF2

8

14

10

17

14

24

1/4

HDF2-F

HDF3

16

27

20

34

29

49

1/2

HDF3-F

HDF4

25

42

30

51

43

73

1/2

HDF4-F

Maximum Operating Pressure 200 psig (13.7 barg), Maximum Operating Temperature 125°F (52°C)

- Models HDF1-F, HDF2-F, HDF3-F use filter Model HF5-12-4DPL.

- Models HDF4-F uses filter Model HF5-16-4DPL.

- Mounting bracket part no. 23.4331-01 and modular connection kit part no. 23.4280.01 are used on all HDF-F models.

NOTE: Dimensions and weights are for reference only. Request certified drawings for construction purposes.



MODEL

DIMENSIONS (INCHES)

WEIGHT

H

W

LBS

HDF1

4

13

13

HDF2

4

12

15

HDF3

4

20

20

HDF4

4

28

23
